Support Block & R-L Transport Automatic Stencil Printer with SMEMA

Categories	Solder Paste Machine
Brand Name:	GKG
Model Number:	G5
Certification:	CE,TUV,ROHS
Place of Origin:	China
MOQ:	1 set
Price:	Negotiable
Payment Terms:	T/T, Western Union, MoneyGram
Supply Ability:	50 sets per month
Delivery Time:	15~20 work days
Packaging Details:	Wooden package
Product Name:	Automatic Stencil Printer
Other Name:	Solder Paste Printing Machine
PCB Size:	50x50~400x340mm
Transport Height:	900±40mm
Width Adjustment:	Automatic
I/Ov Interface:	SMEMA
