Categories | Baggage And Parcel Inspection |
---|---|
Brand Name: | SECUSCAN |
Model Number: | AT10080 |
Certification: | CE, ISO, US.FDA, India-AERB |
Place of Origin: | China |
MOQ: | 1 |
Payment Terms: | T/T, L/C, Western Union |
Supply Ability: | 300 sets/month |
Delivery Time: | One week when there is stock, One month when no stock. |
Packaging Details: | Wooden Packing |
Material: | stainless steel |
Tunnel size: | 1 m * 1 m |
Belt speed: | 0.2 m/s |
Image: | color |
Energy: | duel-energy |
Software: | multi-language |
Gross weight: | 800kg |
Warranty: | 1 year |
Remote control: | yes |
Price: | Negotiable |
Company Info. |
SHENZHEN SECURITY ELECTRONIC EQUIPMENT CO., LIMITED |
Verified Supplier |
View Contact Details |
Product List |
Duel Energy Automated Baggage Handling System To Check Contraband
With a high tunnel opening and a low conveyor, the Secuscan AT10080 is designed for easy loading and unloading of upright baggage. The AT10080’s dual-energy detection provides provides material discrimination so that screeners can identify the material composition of a scanned object, while its compact footprint allows customers to make the most of the available space at a checkpoint.
Specifications:
Tunnel Size: | 1000(W)*800(H)mm |
Conveyor Speed: | 0.22m/s |
Conveyor Max Load: | 200kgs |
Resolution: | <0.101mm Metal Wire |
Penetration: | 34mm Steel |
Film Safety: | Guarantee ISO1600 Film |
X-ray Leakage: | <0.1 μGy/h (at a distance of 5cm From external housing) |
Generate direct: | downward |
Generate angle: | 80 degree |
Anode Voltage: | 100-150Kv |
Anode power: | 0.4 to 1.2mA |
Cooling / Duty Cycle: | Oil Cooling /100% |
X-ray Sensor: | L-Shaped Photodiode Array (mono-energetic), 19bit Deep |
Monitor: | High Resolution Color, LCD Accord, 17 inch |
Image Processing: | Edge enhancement, image strengthening, image lightening, reducing darkening, image returning, image retrieval. |
Image Grey Level: | 65536 |
Image Max Resolution: | 1024 * 1280 pixel |
Image Processing: | 24bit for processing real time |
Image storage: | Storage 100,000 pictures in real time |
Zones & Zoom: | 1-9 Image regions, 2, 4, 8, 16 Times Enlarge, Whole screen continuous observation |
Operation temperature/Humidity: | 0℃-45℃/10%-95%(non-condensing) |
Storage Temperature/Humidity: | -20℃-60℃/10%-95%(non-condensing) |
Operation Power: | 187~240VAC,50/60Hz |
Power Consumption: | 0.8KW(working) |
Noise: | <58db |
Competitive Advantage:
Integrated, cost Effective, Turn-Key Security
Fit for small Baggage and Parcel Security Inspection.
Increased detection capability
Friendly interface for ease-of-use
Reliable performance and uncompromising value
![]() |
