SAE J1772 EV Charging Cable Type 1 80A AC240V 19.2kW IP54 With 25feet UL

SAE J1772 Type 1 Charging Cables 80A 240V 19.2kW with 25feet UL Certificate

Features:

• Conform to the provisions and requirements of SAEJ1772-2012,IEC 62196-2 20162-l
• Using riveting pressure process with none screw ,have a beautiful appearance.Hand-held design conform tothe ergonomic principle , plug conveniently
• XLPO for cable insulation prolonging the aging resistance life-span, TPU sheath improved the bending lifeand wear resistance of cable.
• Excellent protection performance, protection grade achieved lP55 ( working condition )

Mechanical properties

• Mechanical life : no-load plug in/pull out> 10000 times
• Coupled insertion force: >45N<80N

Electrical Performance

• Rated current : 80A
• Operation voltage: 240V
• lnsulation resistance: >1000MQ(DC50Ov)
• Terminall temperature rise :<50K
• withstand voltage : 2000V

Environmental performance
Operating temperature:-30℃~+50°C

Applied Materials

• Case Material: Thermoplastic,flame retardant grade UL94v-o
• Contact Resistance:0.5mQ Max
• Contact bush: Copper alloy,silver plating

Certification: UL
