| Categories | MCU Microcontroller Unit |
|---|---|
| Brand Name: | AT |
| Model Number: | AT32F403ZGT6 |
| MOQ: | 360pcs |
| Payment Terms: | T/T |
| Supply Ability: | 300000PCS/month |
| Delivery Time: | 5-15days |
| Packaging Details: | Bagged |
| product name: | AT32F403ZGT6 |
| Package: | LQFP-144 |
| Manufacturer: | AT |
| Core Processor: | M4 |
| Frequency(MHz): | 200 |
| Flash(KB): | 1024 |
| SRAM(KB): | 96/224 |
| I/O: | 130 |
| Company Info. |
| Beijing Silk Road Enterprise Management Services Co.,LTD |
| Verified Supplier |
| View Contact Details |
| Product List |
AT32F403ZGT6 microcontroller MCU single-chip LQFP144, PIN alternative STM32F446ZCT6 STM32F103ZET6 STM32F303ZCT6
AT32F403ZGT6 microcontroller MCU single-chip LQFP144, PIN
alternative STM32F103ZCT6 STM32F303ZCT6 Software hardware is
completely compatible STM32F103ZET6
1. High compatibility: compatible with Sxx32F103 pins & highly
compatible with software
2.M4 clocked at 200MHz (with FPU/DSP), RAM up to 224KB
3. Rich peripherals: I2C x 3, SDIO x 2, SPI/I2S x 4, 32-bit
Timer...
4. Support SPIM and external high-speed SPI NOR Flash
5. High computing power, one can replace multiple
Hot sell
| STM32F103VET6 | STM32F427ZGT6 | STM32F105ZDT6 | STM32F030G4U6 | STM32F070F6U6 |
| STM32F103VCT6 | STM32F427ZIT6 | STM32F105ZET6 | STM32F030G6U6 | STM32F070F8U6 |
| STM32F103C8T6 | STM32F427ZKT6 | STM32F105ZFT6 | STM32F030G8U6 | STM32F070G4U6 |
| STM32F103RCT6 | STM32F427IGH6 | STM32F105ZGT6 | STM32F030G4U6 | STM32F070G6U6 |
| STM32F103RBT6 | STM32F427IIH6 | STM32F105ZIT6 | STM32F030G6U6 | STM32F070G8U6 |
| STM32F103T4U6 | STM32F427IKH6 | STM32F101T4U6 | STM32F030G8U6 | STM32F070G4U6 |
| STM32F103T6U6 | STM32F407RET6 | STM32F101T6U6 | STM32F030K4U6 | STM32F070G6U6 |
| STM32F103T8U6 | STM32F407RGT6 | STM32F101T8U6 | STM32F030K6U6 | STM32F070G8U6 |
| STM32F103TBU6 | STM32F407RKT6 | STM32F101TBU6 | STM32F030K8U6 | STM32F070K4U6 |
| STM32F103C4T6 | STM32F407VET6 | STM32F101C4T6 | STM32F030C4U6 | STM32F070K6U6 |
| STM32F103C6T6 | STM32F407VGT6 | STM32F101C6T6 | STM32F030C6U6 | STM32F070K8U6 |
| STM32F103CBT6 | STM32F407VKT6 | STM32F101C8T6 | STM32F030C8U6 | STM32F070C4U6 |
| STM32F103R4T6 | STM32F407ZET6 | STM32F101CBT6 | STM32F030R8U6 | STM32F070C6U6 |
| STM32F103R6T6 | STM32F407ZGT6 | STM32F101R4T6 | STM32F207RCT6 | STM32F070C8U6 |
| STM32F103R8T6 | STM32F407ZKT6 | STM32F101R6T6 | STM32F207RET6 | STM32F070R8U6 |
| STM32F103RBT6 | STM32F407VEH6 | STM32F101R8T6 | STM32F207RGT6 | STM32F105RBT6 |
| STM32F103RDT6 | STM32F407VGH6 | STM32F101RBT6 | STM32F207RKT6 | STM32F105RCT6 |
| STM32F103RET6 | STM32F407VKH6 | STM32F101RCT6 | STM32F207VCT6 | STM32F105RDT6 |
| STM32F103RFT6 | STM32F407IEH6 | STM32F101RDT6 | STM32F207VET6 | STM32F105RET6 |
| STM32F103RGT6 | STM32F407IGH6 | STM32F101RET6 | STM32F207VGT6 | STM32F105RFT6 |
| STM32F103RIT6 | STM32F4071KH6 | STM32F101RFT6 | STM32F207VKT6 | STM32F105RGT6 |
| STM32F103RKT6 | STM32F405RET6 | STM32F101RGT6 | STM32F207ZCT6 | STM32F105RIT6 |
| STM32F103V8T6 | STM32F405RGT6 | STM32F101RIT6 | STM32F207ZET6 | STM32F105RKT6 |
| STM32F103VBT6 | STM32F405RKT6 | STM32F101RKT6 | STM32F207ZGT6 | STM32F105V8T6 |
| STM32F103VDT6 | STM32F405VGT6 | STM32F101V8T6 | STM32F207ZKT6 | STM32F105VBT6 |
| STM32F103VFT6 | STM32F405VKT6 | STM32F101VBT6 | STM32F207IET6 | STM32F105VCT6 |
| STM32F103VGT6 | STM32F405ZGT6 | STM32F101VCT6 | STM32F207IGT6 | STM32F105VDT6 |
| STM32F103VIT6 | STM32F405ZKT6 | STM32F101VDT6 | STM32F207IKT6 | STM32F105VET6 |
| STM32F103VKT6 | STM32F405VGH6 | STM32F101VET6 | STM32F427VET6 | STM32F105VFT6 |
| STM32F103ZCT6 | STM32F405VKH6 | STM32F101VFT6 | STM32F427VGT6 | STM32F105VGT6 |
| STM32F103ZDT6 | STM32F205VCT6 | STM32F101VGT6 | STM32F427VIT6 | STM32F105VIT6 |
| STM32F103ZET6 | STM32F205VET6 | STM32F101VIT6 | STM32F427VKT6 | STM32F105VKT6 |
| STM32F103ZFT6 | STM32F205VGT6 | STM32F101VKT6 | STM32F427ZET6 | STM32F105ZCT6 |
| STM32F103ZGT6 | STM32F205VKT6 | STM32F101ZCT6 | STM32F205ZGT6 | STM32F101ZFT6 |
| STM32F103ZIT6 | STM32F205ZCT6 | STM32F101ZDT6 | STM32F205ZKT6 | STM32F101ZGT6 |
| STM32F030C8T6 | STM32F205ZET6 | STM32F101ZET6 | STM32F070F4U6 | STM32F101ZIT6 |
| STM32F030F4U6 | STM32F030F6U6 | STM32F030F8U6 | STM8S003F3P6 | STM32L151VCT6 |
| Sxx Series | Sxx Part | Core | CPU | DSP/FPU | Flash | SRAM | AT32 Series | AT32 Part | Core | CPU | DSP/FPU | Flash | SRAM |
| Sxx32F103 | C8T6 | M3 | 72MHz | No/No | 64K | 20K | AT32F413 | C8T7 | M4 | 200MHz | Yes/Yes | 64K | 32K |
| Sxx32F103 | CBT6 | M3 | 72MHz | No/No | 128K | 20K | AT32F413 | CBT7 | M4 | 200MHz | Yes/Yes | 128K | 16/32/64K |
| Sxx32F103 | CBU6 | M3 | 72MHz | No/No | 128K | 20K | AT32F413 | CBU7 | M4 | 200MHz | Yes/Yes | 128K | 16/32/64K |
| Sxx32F103 | RBT6 | M3 | 72MHz | No/No | 128K | 20K | AT32F413 | RBT7 | M4 | 200MHz | Yes/Yes | 128K | 16/32/64K |
| Sxx32F103 | RCT6 | M3 | 72MHz | No/No | 256K | 48K | AT32F413 | RCT7 | M4 | 200MHz | Yes/Yes | 256K | 16/32/64K |
| Sxx32F103 | RCT6 | M3 | 72MHz | No/No | 256K | 48K | AT32F403A | RCT7 | M4 | 240MHz | Yes/Yes | 256K | 96/224K |
| Sxx32F103 | RET6 | M3 | 72MHz | No/No | 512K | 64K | AT32F403A | RGT7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F103 | RGT6 | M3 | 72MHz | No/No | 1024K | 96K | AT32F403A | RGT7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F103 | VCT6 | M3 | 72MHz | No/No | 256K | 48K | AT32F403A | VCT7 | M4 | 240MHz | Yes/Yes | 256K | 96/224K |
| Sxx32F103 | VET6 | M3 | 72MHz | No/No | 512K | 64K | AT32F403A | VGT7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F103 | VGT6 | M3 | 72MHz | No/No | 1024K | 96K | AT32F403A | VGT7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F103 | ZCT6 | M3 | 72MHz | No/No | 256K | 48K | AT32F403 | ZGT6 | M4 | 200MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F103 | ZET6 | M3 | 72MHz | No/No | 512K | 64K | AT32F403 | ZGT6 | M4 | 200MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F103 | ZGT6 | M3 | 72MHz | No/No | 1024K | 96K | AT32F403 | ZGT6 | M4 | 200MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F105 | RBT6 | M3 | 72MHz | No/No | 128K | 64K | AT32F403A | RCT7 | M4 | 240MHz | Yes/Yes | 256K | 96/224K |
| Sxx32F105 | RCT6 | M3 | 72MHz | No/No | 256K | 64K | AT32F403A | RCT7 | M4 | 240MHz | Yes/Yes | 256K | 96/224K |
| Sxx32F105 | VCT6 | M3 | 72MHz | No/No | 256K | 64K | AT32F403A | VCT7 | M4 | 240MHz | Yes/Yes | 256K | 96/224K |
| Sxx32F205 | RCT6 | M3 | 120MHz | No/No | 256K | 64K | AT32F403A | RCT7 | M4 | 240MHz | Yes/Yes | 256K | 96/224K |
| Sxx32F205 | RET6 | M3 | 120MHz | No/No | 512K | 96K | AT32F403A | RGT7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F205 | RGT6 | M3 | 120MHz | No/No | 1024K | 128K | AT32F403A | RGT7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F205 | VCT6 | M3 | 120MHz | No/No | 256K | 64K | AT32F403A | VCT7 | M4 | 240MHz | Yes/Yes | 256K | 96/224K |
| Sxx32F205 | VET6 | M3 | 120MHz | No/No | 512K | 96K | AT32F403A | VGT7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F205 | VGT6 | M3 | 120MHz | No/No | 1024K | 128K | AT32F403A | VGT7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F205 | ZCT6 | M3 | 120MHz | No/No | 256K | 64K | AT32F403 | ZGT6 | M4 | 200MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F205 | ZET6 | M3 | 120MHz | No/No | 512K | 96K | AT32F403 | ZGT6 | M4 | 200MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F205 | ZGT6 | M3 | 120MHz | No/No | 1024K | 128K | AT32F403 | ZGT6 | M4 | 200MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F207 | VCT6 | M3 | 120MHz | No/No | 256K | 128K | AT32F407A | VCT7 | M4 | 240MHz | Yes/Yes | 256K | 96/224K |
| Sxx32F207 | VET6 | M3 | 120MHz | No/No | 512K | 128K | AT32F407A | VGT7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F207 | VGT6 | M3 | 120MHz | No/No | 1024K | 128K | AT32F407A | VGT7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F302 | C8T6 | M4 | 72MHz | Yes/Yes | 64K | 16K | AT32F413 | C8T7 | M4 | 200MHz | Yes/Yes | 64K | 32k |
| Sxx32F302 | CBT6 | M4 | 72MHz | Yes/Yes | 128K | 16K | AT32F413 | CBT7 | M4 | 200MHz | Yes/Yes | 128K | 16/32/64K |
| Sxx32F302 | CCT6 | M4 | 72MHz | Yes/Yes | 256K | 40K | AT32F413 | CCT7 | M4 | 200MHz | Yes/Yes | 256K | 16/32/64K |
| Sxx32F302 | RBT6 | M4 | 72MHz | Yes/Yes | 128K | 32K | AT32F413 | RBT7 | M4 | 200MHz | Yes/Yes | 128K | 16/32/64K |
| Sxx32F302 | RCT6 | M4 | 72MHz | Yes/Yes | 256K | 40K | AT32F413 | RCT7 | M4 | 200MHz | Yes/Yes | 256K | 16/32/64K |
| Sxx32F302 | RET6 | M4 | 72MHz | Yes/Yes | 512K | 64K | AT32F403A | RGT7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F302 | VCT6 | M4 | 72MHz | Yes/Yes | 256K | 40K | AT32F403A | VCT7 | M4 | 240MHz | Yes/Yes | 256K | 96/224K |
| Sxx32F302 | VET6 | M4 | 72MHz | Yes/Yes | 512K | 64K | AT32F403A | VGT7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F303 | C8T6 | M4 | 72MHz | Yes/Yes | 64K | 16K | AT32F413 | C8T7 | M4 | 200MHz | Yes/Yes | 64K | 32K |
| Sxx32F303 | K8T6 | M4 | 72MHz | Yes/Yes | 64K | 16K | AT32F413 | KBU7 | M4 | 200MHz | Yes/Yes | 128K | 16/32/64K |
| Sxx32F303 | CBT6 | M4 | 72MHz | Yes/Yes | 128K | 40K | AT32F413 | CBT7 | M4 | 200MHz | Yes/Yes | 128K | 16/32/64K |
| Sxx32F303 | CCT6 | M4 | 72MHz | Yes/Yes | 256K | 48K | AT32F413 | CCT7 | M4 | 200MHz | Yes/Yes | 256K | 16/32/64K |
| Sxx32F303 | RBT6 | M4 | 72MHz | Yes/Yes | 128K | 40K | AT32F413 | RBT7 | M4 | 200MHz | Yes/Yes | 128K | 16/32/64K |
| Sxx32F303 | RCT6 | M4 | 72MHz | Yes/Yes | 256K | 48K | AT32F413 | RCT7 | M4 | 200MHz | Yes/Yes | 256K | 16/32/64K |
| Sxx32F303 | RET6 | M4 | 72MHz | Yes/Yes | 512K | 80K | AT32F403A | RGT7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F303 | VCT6 | M4 | 72MHz | Yes/Yes | 256K | 48K | AT32F403A | VCT7 | M4 | 240MHz | Yes/Yes | 256K | 96/224K |
| Sxx32F303 | VET6 | M4 | 72MHz | Yes/Yes | 512K | 80K | AT32F403A | VGT7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F303 | ZET6 | M4 | 72MHz | Yes/Yes | 512K | 80K | AT32F403 | ZGT6 | M4 | 200MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F401 | CBU6 | M4 | 84MHz | Yes/Yes | 128K | 64K | AT32F413 | KBU7 | M4 | 200MHz | Yes/Yes | 128k | 16/32/64K |
| Sxx32F401 | CCU6 | M4 | 84MHz | Yes/Yes | 256K | 64K | AT32F413 | CCU7 | M4 | 200MHz | Yes/Yes | 256K | 16/32/64K |
| Sxx32F401 | RBT6 | M4 | 84MHz | Yes/Yes | 128k | 64K | AT32F413 | RBT7 | M4 | 200MHz | Yes/Yes | 128K | 16/32/64K |
| Sxx32F401 | RCT6 | M4 | 84MHz | Yes/Yes | 256K | 64K | AT32F413 | RCT7 | M4 | 200MHz | Yes/Yes | 256K | 16/32/64K |
| Sxx32F401 | VCT6 | M4 | 84MHz | Yes/Yes | 256K | 64K | AT32F403A | VCT7 | M4 | 240MHz | Yes/Yes | 256K | 96/224K |
| Sxx32F401 | RET6 | M4 | 84MHz | Yes/Yes | 512K | 96K | AT32F403A | RGT7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F401 | VET6 | M4 | 84MHz | Yes/Yes | 512K | 96K | AT32F403A | VGT7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F411 | CCU6 | M4 | 100MHz | Yes/Yes | 256K | 128K | AT32F403A | CCU7 | M4 | 240MHz | Yes/Yes | 256K | 96/224K |
| Sxx32F411 | CEU6 | M4 | 100MHz | Yes/Yes | 512K | 128K | AT32F403A | CGU7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F411 | RCT6 | M4 | 100MHz | Yes/Yes | 256K | 128K | AT32F403A | RCT7 | M4 | 240MHz | Yes/Yes | 256K | 96/224K |
| Sxx32F411 | RET6 | M4 | 100MHz | Yes/Yes | 512K | 128K | AT32F403A | RGT7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F411 | VCT6 | M4 | 100MHz | Yes/Yes | 256K | 128K | AT32F403A | VCT7 | M4 | 240MHz | Yes/Yes | 256K | 96/224K |
| Sxx32F411 | VET6 | M4 | 100MHz | Yes/Yes | 512K | 128K | AT32F403A | VGT7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F405 | RGT6 | M4 | 168MHz | Yes/Yes | 1024K | 192K | AT32F403A | RGT7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F405 | VGT6 | M4 | 168MHz | Yes/Yes | 1024K | 192K | AT32F403A | VGT7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F405 | ZGT6 | M4 | 168MHz | Yes/Yes | 1024K | 192K | AT32F403 | ZGT6 | M4 | 200MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F446 | RCT6 | M4 | 180MHz | Yes/Yes | 256K | 128K | AT32F403A | RCT7 | M4 | 240MHz | Yes/Yes | 256K | 96/224K |
| Sxx32F446 | RET6 | M4 | 180MHz | Yes/Yes | 512K | 128K | AT32F403A | RGT7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F446 | VCT6 | M4 | 180MHz | Yes/Yes | 256K | 128K | AT32F403A | VCT7 | M4 | 240MHz | Yes/Yes | 256K | 96/224K |
| Sxx32F446 | VET6 | M4 | 180MHz | Yes/Yes | 512K | 128K | AT32F403A | VGT7 | M4 | 240MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F446 | ZCT6 | M4 | 180MHz | Yes/Yes | 256K | 128K | AT32F403 | ZGT6 | M4 | 200MHz | Yes/Yes | 1024K | 96/224K |
| Sxx32F446 | ZET6 | M4 | 180MHz | Yes/Yes | 512K | 128K | AT32F403 | ZGT6 | M4 | 200MHz | Yes/Yes | 1024K | 96/224K |
|
