| Categories | Paper Making Machine |
|---|---|
| Brand Name: | HUATAO |
| Model Number: | HT027 |
| Certification: | CE |
| Place of Origin: | CHINA |
| MOQ: | 1pc |
| Payment Terms: | L/C,T/T,Western Union,MoneyGram |
| Supply Ability: | 20sets/moth |
| Delivery Time: | 15days |
| Packaging Details: | exported package |
| Processing Type:: | Pulp Molding Machine |
| Voltage:: | 220V/380V |
| Dimension(L*W*H):: | 2300mm*1950mm*1600mm |
| Power(W):: | 28kw~50kw |
| Weight:: | 2.5ton |
| Warranty:: | 1 YEAR, 12 months |
| Capacity:: | 1800-2000pcs/hour |
| Frequency:: | 50Hz-60Hz |
| packaging: | standard export package |
| Company Info. |
| HUATAO LOVER LTD |
| Verified Supplier |
| View Contact Details |
| Product List |
| Processing Type | Pulp Molding Machine |
| Voltage | 220V/380V |
| Dimension (L*W*H) | 2300mm*1950mm*1600mm |
| Power | 28kw~50kw |
| Weight | 2.5ton |
| Warranty | 1 YEAR, 12 months |
| Capacity | 1800-2000pcs/hour |
| Frequency | 50Hz-60Hz |
This pulp molding machine uses waste paper as raw material to produce various products including egg trays, cartons, boxes, fruit trays, industrial trays, and seedling trays. The complete system includes pulp making, forming, and drying components.
| Model | Capacity | Mould/pc | Weight (KG) | Dimension (L*W*H) | Motor (KW) | Workers |
|---|---|---|---|---|---|---|
| QS1*3 | 1000-1400 | 3 | 650 | 2300×2150×1850 | 2.2 | 3-4 |
| QS1*4 | 1500-1800 | 4 | 700 | 2550×2150×1850 | 3 | 3-4 |
| QS3*4 | 1800-2000 | 12 | 1350 | 2850×1750×1600 | Speed adjustable-3 | 4-5 |
| QS4*4 | 2000-2500 | 16 | 1500 | 3200*1700*16000 | Speed adjustable-3 | 4-5 |
| QS4*8-1 | 3000-3500 | 32 | 2100 | 2600×2250×2300 | Speed adjustable-3 | 3-4 |
| QS4*8-2 | 4000-5000 | 32 | 2200 | 3000X2200x2300 | Speed adjustable-3 | 5-6 |
Pulping System: Waste paper is pulped in the pulper, with crushed pulp entering the pulp pool through hydraulic and friction action.
Forming System: Uses negative pressure and vacuum adsorption to convert pulp into products. Different molds create various tray types.
Drying System: Wet products are dried on a conveyor belt through a metal oven (180-250°C).
Packing System: Finished products are automatically stacked and packed for transport.
|
