| Categories | TFT LCD Module |
|---|---|
| Brand Name: | ROYAL DISPLAY |
| Model Number: | AT070TN92 |
| Certification: | ROHS, ISO |
| Place of Origin: | China |
| MOQ: | 500pcs |
| Price: | Negotiable |
| Supply Ability: | 300K/M |
| Delivery Time: | 15-20 work days |
| Packaging Details: | Cartons, Capboard, EPE, Blister Tray |
| Product Type: | TFT LCD |
| Display type: | TFT LCD |
| Operating Temp.: | -20°C~+70°C |
| Storage Temp.: | -30°C~+80°C |
| Certificate: | Ce, RoHS, SGS |
| Active Area(mm): | 164.9*100*7.13 |
| Surface Treatment: | Anti-Glare |
| Electrical Interface: | Lvds |
| Company Info. |
| Royal Display Co.,Limited |
| Verified Supplier |
| View Contact Details |
| Product List |
| Module number | AT070TN92 |
| Resolution | 800x480 |
| Pixel pitch | 0.05(W) × 0.15(H) mm |
| Active Area | 164.9*100*7.13 |
| View angle | R/L/U/D 75/75/70/75(Deg) |
| Pixel Arrangement | RGB Vertical Stripe |
| Surface Treatment | Anti-glare |
| Electrical Interface | LVDS |
| Brightness | 500(cd/m2) |
| Contrast ratio | 500:01:00 |
| Outline dimension | 165.75(W) ×105.39(H) ×3.4(D) mm |
| Backlight | LED |
| Response time | 25(ms) |
| Display mode | TN, Normally White, Transmissive |
| Operate temperature | -30-85(°C) |
| Storage temperature | -30-85(°C) |
| Display Colors | 262k/16.7M(6 bit/ 6 bit + Dithering) |
| Power Consumption | 1.90W(Typ.) |
| Power Supply Voltage | 3.3v(Typ.) |
| Backlight lifetime | 20k hrs(Min.) |
WHY CHOOSE ROYAL DISPLAY?
1. Best Quality
---THREE times of inspection on all products on production:
Step 1: Raw Material check
Step 2: Process check and full inspection after wire bonding&chip bonding
Step 3: full test before packaging and partial check before shippment
2. Best Price
---manufacturer
---best suppliers sources
---all products by oneself
3.Company strength
---good quality&competitive price
---Listed company
---Management System: ISO 9001:2015
4.Rich experiences
---Over 10 years experiences in Lcd display field.
TFT ADVANTAGES
1.High quality of TFT LCD screens.
2.The visible area of TFT LCD screens is large.
3.TFT LCD screens have a wide range of applications.
4.TFT LCD screens have no electromagnetic radiation.
5.TFT LCD screens digital interface.
6.TFT LCD screens "figure" symmetrical and small.
7. The effect of TFT LCD screens is good
8. Low power consumption of TFT LCD screens
OUR SERVICE ADVANTAGES
1, Quality Control: Every LCD tested with special instruments or
main boards before delivery to ensure working. Both Original and
High quality OEM products available.
2, Packing: Packed in anti-static bags with foam box to ensure
safety in transportation.
3, Payment Terms: T/T, Western Union,L/C, PayPal
4, Shipping Methods: Prompt delivery by UPS, EMS, DHL, TNT, or by
air.
5, Service: Best after-sales service to ensure satisfaction from
customers.
6, Warranty: Usually, product warranty for one year.
7, Samples: Our company offers samples for quality test or other
business purposes, but we kindly ask you to pay for samples and the
freight.
8. If mass production has any quality problem, customer can return
it.
