| Categories | Trailer Mounted Drilling Rigs |
|---|---|
| Model Number: | GK-200 |
| Place of Origin: | China |
| MOQ: | Negotiation |
| Price: | Negotiation |
| Delivery Time: | Within 7-12 days |
| Payment Terms: | L/C, D/A, T/T, Western Union |
| Brand Name: | ShiTan |
| Certification: | ISO9001 |
| Type: | Rotary Drilling Rig |
| Engine: | Disel engine |
| Usage: | Water Well |
| model: | GK-200 |
| Drilling hole diameter(mm): | 75,91,110,130,150,300 |
| Drilling depth (m): | 200,150,100,70,50,30 |
| Drill pipe diameter (mm): | 42.50 |
| After-sales service provided: | Engineers available to service machinery overseas |
| Product name: | crawler mounted Mining Drilling Rig Portable Water Well Drilling Rig |
| Application: | water well drilling,Geological exploration |
| Company Info. |
| Jinzhou City Shitan Machinery Equipment CO. LTD. |
| Verified Supplier |
| View Contact Details |
| Product List |
Mobile GK200 Diesel Exploratory Drilling Crawler Mounted Drill Rig
Product Description
The GK-200 mobile drilling rig is a kind of widely used and hydraulic feeding drill, which has the characteristics of big power, great lifting force (2T) and high transmission torque. It can be used in engineering geological survey of railway, hydropower, transportation, bridge, foundation and other buildings, geological core drilling and physical exploration and so on.
Gk 200 Soil Testing Drilling Rig Technical Data:
| GK 200 Drilling Rig for soil testing | |
| Drilling hole diameter(mm) | 75,91,110,130,150,300 |
| Drilling depth (m) | 200,150,100,70,50,30 |
| Drill pipe diameter (mm) | 42,50 |
| Drilling angle(°) | 90~75 |
| Equipment size(L * B * H) | 1730 * 860 * 1360 (mm) |
| Rig weight (except engine) | 700 |
| Gyrator | |
| Spindle speed (four gear) (r/min) | 115,230,505,1010 |
| Spindle travel(mm) | 450 |
| Spindle no-load lifting maximum moving speed(m/s) | 0.05 |
| Spindle no load drop maximum movement speed(m/s) | 0.067 |
| Spindle maximum feed pressure(KN) | 15 |
| Spindle maximum lifting force(KN) | 25 |
| Spindle maximum output torque(KN• m) | 1.5 |
Gk 200 Soil Testing Drilling Rig Machine Features
1. Very powerful at soil, sand, hard rock, etc. land condition.
2. Three kinds drill bits (three-wing bit, alloy bit and diamond bit) available for your choice, which can drill both soft and hard ground, especially diamond drill bit effective in drilling hard rocks.
3. Hydraulic control system for greatly improving the working efficiency, saving labor force.
4. Mounted wheel or trailer, can be hauled easily by car or tractor, convenient to transport.
5. Power can be diesel engine or electric motor, as per your request.
Tips to select a right drilling rig:
1. What kind of projects you will work for?
Water well, Borehole, Exploration coring, Foundation Piling, Blast holes, Geothermal heat project or others?
2. Max drilling depth you want.
100m, 150m, 200m, 300m, or other depth.
3. The Min and Max borehole diameter you need.
Like Max 200mm, Min 75mm.
|
