| Categories | High Temperature Ovens |
|---|---|
| Brand Name: | ASLI |
| Model Number: | RHD-90 |
| Certification: | CE |
| Place of Origin: | China |
| MOQ: | 1 set |
| Price: | negotiate |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 200 sets per month |
| Delivery Time: | 15 workdays |
| Packaging Details: | standard export plywood case |
| Internal Dimension: | W600*H900*D500mm |
| Volume: | 270 Liters |
| Temperature Range: | (RT+15℃)~300℃ |
| Temperature Control Accuracy: | +/- 0.5℃ |
| from R.T. to 200℃: | approx. 35mins |
| Control Method: | Micro PID+SSR+Timer |
| Storage Shelf: | Two layers |
| Heating Rate: | 5℃/Min |
5℃/Min Heating Rate Plastic Testing Machine Temperature Aging Test Oven
Model | RHD - 45 | RHD - 60 | RHD - 90 | RHD - 120 |
Internal Dimension W×H×D(mm ) | 450×400×400 | 500×600×500 | 600×900×500 | 800×1200×700 |
External Dimension W×H×D(mm ) | 650×900×550 | 700×1200×650 | 850× 1600×700 | 1200× 1680×900 |
Interior and Exterior Material | Interior material is SUS 304# stainless steel, exterior is stainless steel or SEE cold-rolled steel with paint coated. | |||
Temperature Range | R.T. to 200; (300 to 500°C is optional) | |||
Indication Resolution/ Distribution Uniformity of Temperature | 0.1°C/±2.0°C;( When temperature is 100°C) | |||
Control Accuracy of Temperature | ±0.5°C; | |||
Temperature Rising Velocity | Temperature rising velocity: from R.T. to 200°C,needs approx. 35mins | |||
Control Method | Micro PID+SSR+Timer | |||
Storage Shelf | Two layers | |||
Viewing Window | When temperature is RT to 200°C ,with viewing widow When temperature is 200°C to 500°C ,without viewing widow | |||
Power | AC 220V 50/60HZ ; AC 380V 50/60HZ | |||
 |  |
 |  |
Freestanding electric oven can provide a stable test space for pre-heating, drying, changes about physics and chemistry testing . It supplys precision temperature controllter with high stability of platinum resistance to temperature that makes temperature well-distribution.
Aging test oven Features
1.Outside SECC steel, fine powder coating treatment; Inner SUS#304
stainless steel.
2.Use new high temperature resistant long shaft motor
3 Turbine fan.
4.Silicone forced tight
5.Over temperature protection, super load automatic power system.
6.Circulation system: air force level cycle.
7. Heating system:PID+S.S.R.
8.The thermostat: PID microcomputer control, automatic constant
temperature, temperature quickly compensation function
9.Timer: temperature to time, when the power failure alarm
indication.
10.According to customer demand matching glass window can be
customized according to customer specifications specified.
Package: PP film first, and then 10mm foam between machine and the case, and outside is standard export plywood case.
