| Categories | Solar Street Light With Camera |
|---|---|
| Brand Name: | Road Smart |
| Model Number: | SC-NH80-S1 |
| Certification: | ISO, SGS, CQC, IP65, CE, RoHS, FCC |
| Place of Origin: | Shenzhen |
| MOQ: | 1set |
| Price: | negotiation |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000sets/year |
| Delivery Time: | 8-10 work days |
| Packaging Details: | Color Box Packed, Anti-Shocked Package Material; |
| Panel Power: | 80W/18V |
| Material: | Mono crystalline silicon |
| Solar cell efficiency: | 18-20% |
| Capacity: | 340WH/12.8V |
| Charge cycle times: | 2000 times |
| Luminous flux: | 3000-3500lm |
Parameter
| Type | SC-NH65-S2 SC-NH65-S3 | SC-NH80-S2 SC-NH80-S3 | SC-NH100-S2 SC-NH100-S3 | SC-NH150-CS2 SC-NH150-CS3 | |
| Panel | Power | 65W/18V | 80W/18V | 100W/18V | 120W/18V |
| Material | Mono Crystalline Silicon | ||||
| Solar cell efficiency | 19-20% | 19-20% | 19-20% | 19-20% | |
Lithium battery | Capacity | 212WH/12.8V | 340WH/12.8V | 424WH/12.8V | 610WH/11.1V |
| Charge cycle times | 2000 times | 2000 times | 2000 times | 2000 times | |
Lamp head | Luminous flux | 2000-2500lm | 3000-3500lm | 4500-5000lm | 6000-6500lm |
| Light output | 15W | 20W | 30W | 40w | |
| Color temperature | 3000K-6500K | ||||
| LED chip | Bridgelux | ||||
| Color temperature | 6000K | ||||
| CRI | >70Ra | ||||
| Material of lamp head | Aluminum alloy | ||||
| Elevation angle | 12 (attention to Dialux use) | ||||
| Lifespan | 50000hrs | ||||
| System | Light control voltage | 5V | |||
| Light distribution | Batwing lens with polarized light | ||||
| Beam angle | X-axis:140 Y-axis:50 | ||||
| Lighting time(full charged) | 3-4 rainy days | ||||
| Operation temperature | -20~60 | ||||
| Installation | Top diameter of pole | 70mm | |||
| Mounting height | 5-12m | ||||
| Installation spacing | 20-30m | ||||
Note:
1. S2 means WIFI version (built-in WIFI wireless module).
2. S3 means 4G version 4G Module and built-in WIFI wireless module.


|
