| Categories | Vacuum Coating Machine |
|---|---|
| Brand Name: | ZYD |
| Model Number: | ZYD-22M |
| Certification: | CE |
| Place of Origin: | CHINA |
| MOQ: | 1PCS |
| Price: | USD100000 |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 10PCS/MONTH |
| Delivery Time: | 50Days |
| Packaging Details: | NAKE PLASTIC COVER PACKING |
| Type: | Vacuum coating machine |
| Power: | 210KW |
| Voltage: | 380V |
| chamber size: | 1200L |
| Water pressure: | ≥0.2MPa |
| Air pressure: | 0.5-0.8MPa |
1. Certified ISO9001
2. Nice after-sales service
3. Strong technology
4. Size can be customized
5. Chamber made of stainless stee
1. Hardwares multi-arc plasma coating machine
Configuration :ZJP-300 Roots pump ,2X-70&2X-8 Mechanical pump,KT-700 Diffusion pump.
The founction of multi-Arc Lon planting coated with TiN,TiCN,CrN ,ZrN or other same kind coating with hard diamond,which enhance the attachment with one another .This coating is also used to make watch,galsses,cooks and must be wear and hard.
2. Titanium adhesive coating machine
vacuum multi-arc ion coating machine is the advanced special equipment for coating PVD film on
the surface of many products in the world. It used PLC and touch screen to realize automation and logic programmable control operation. It has reasonable structure ,elegant appearance ,stable performance and man-machine operation style. It is simple and easy to use. The film is firm and has good compactness. It is the ideal equipment for industry production.
| 3. Multi-functional golden coating machine | ||||||
| Model | ZYD-800 | ZYD-1000 | ZYD-1300 | ZYD-1600 | ZYD-1800 | ZYD-2200 |
| Vacuum chamber | 800*800 | 1000*1100 | 1300*1500 | 1600*1800 | 1800*3000 | 2200*4000 |
| Arc target amount | 4 or 6pcs | 6 or 8pcs | 10 or 12pcs | 16 or 18pcs | 30 or 32pcs | 38 or 40pcs |
| bias supply | 15KW/pcs | 20KW/ pcs | 30KW/ pcs | 50KW/pcs | 60KW/pcs | 80KW/ pcs |
| Total power | 30KW | 40KW | 55KW | 80KW | 125KW | 195KW |
| Power supply type | Arc power source, filament power, pulsed bias power supply | |||||
| Chamber structure | Vertical & front door, rear pumping system, double water-cooling chamber | |||||
| Chamber material | Stainless steel | |||||
| Ultimate vacuum | 6.0×10-4Pa | |||||
| Pump-down time | 8.0×10-3Pa≤15min | |||||
| Vacuum system | Diffusion pump or molecular pump +Roots pump +Mechanical pump+ holding pump(can be allocated by customer’s requests) | |||||
| Workpiece system | Rotation of the planet forms, frequency regulation(adjusting rotation speed) | |||||
Workpiece heating temperature | From room temperature to 450°C, adjustable control(PID temperature control) | |||||
| Process gas | 3-channel or 4-way process gas flow control and display system, matching automatic refueling systems | |||||
| Water-cooling system | Water circulation cooling system, and water tower or industrial chiller or deep-cooling system(supply by customer) | |||||
| Control method | Manual/automatic all-in-one,touch screen,PLC or computer operation | |||||
| Alarming and protection | Alarming for short of water, overcurrent, overvoltage and circuit break, etc of pump and target, and carry out protections and electrical interlocking functions | |||||
Other technical parameters | Water pressure≥0.2MPa,water temperature≤25°C,air pressure0.5-0.8MPa | |||||
| Remarks | Configuration of coating equipment can be designed according to the requirement of the coated | |||||
|
