| Categories | Fruit Box Mold |
|---|---|
| Service: | DFM, Mold Design, Manufacturing and In-House Trial。 |
| Sheet Material: | PET |
| Mold Type: | Fruit Box Thermoforming Mold |
| Mold Material: | 6061 Aluminum; 7075 Available When Required。 |
| Lead Time: | About 5 Weeks After Deposit and Final Drawing Approval。 |
| Payment Terms: | 60% T/T Deposit,40% Balance Before Shipment |
| Cooling System: | Integrated cooling channels for stable mold temperature and cycle control |
| Surface treatment: | Polishing |
| Forming Process: | positive-negative pressure forming |
| Cutting Method: | Steel Rule Die Cutting |
| Price: | Negotiable |
| Product Application: | Blueberry, strawberry, grape, tomato and fresh-produce packaging |
| Stacking Method: | Mechanical down stacking |
| Surface Treatment: | Polishing / Mirror Polishing / Hard Anodizing / PTFE Coating / Sandblasting |
| Certification: | ISO 9001 |
| Packaging Details: | Export Plywood Case with Moisture-Proof Protection |
| Delivery Time: | Approximately 4–5 weeks after the deposit is paid and the final drawings are approved. |
| Shaping Mode: | Positive‑Negative Pressure Thermoforming |
| Tolerance: | 0.03mm -0.05mm, Depending on the Component。 |
| Sheet Thickness: | As the customer's demand |
| Place of Origin: | Shenzhen, China |
| Brand Name: | HXW Mold |
| MOQ: | 1 Set |
| Company Info. |
| Shenzhen Hexingwang Technology Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
HXW Mold designs and manufactures custom food container thermoforming molds for takeaway boxes, meal trays, bowls and other rigid food packaging products.
Tooling can be developed for hinged clamshells, punnets, open trays and separate-lid packaging, with forming, punching, trimming and stacking solutions matched to the product and production line.
Fruit packaging tooling requires coordinated control of ventilation, closure, hinge performance, transparent appearance and stacking direction.
Ventilation holes or slots are positioned according to the packaging structure while maintaining clean and consistent hole placement.
For clamshell packaging, the closure and hinge areas are developed to support reliable opening, closing and product handling.
The stacking layout can be arranged according to the required automation direction and production-line configuration.
Trial samples can be checked for closure, stacking performance and overall appearance before shipment.
Please provide the product drawing or physical sample, machine model, forming area, PP sheet thickness and target output for cavity-layout evaluation and quotation.
Yes. Tooling can be developed for hinged clamshells, punnets, open trays and separate-lid fruit packaging according to the product design.
Please provide the product drawing or physical sample, product dimensions, sheet material and thickness, machine brand and model, forming area, required cavity quantity, cutting method, stacking method and target output.
Yes. We customize the mounting plate, installation dimensions, positioning, water connections, vacuum or pressure connections, cutting interface and stacking interface according to your machine drawing.
The project passes drawing review, DFM analysis, mold design, CNC machining, dimensional inspection, assembly inspection, cooling and air-circuit testing, and in-house mold trials. Trial videos and formed samples can be provided for approval.
Yes. Ventilation holes or slots can be incorporated according to the product design and required packaging function.
Send us your product drawing or physical sample together with the machine model, forming area, PP sheet thickness and target output. Our engineering team will evaluate the cavity layout and tooling requirements before quotation.
|
