Automatic Half Height Turnstile Gate with Stainless Steel 304 IP54 Protection and 0.4s Barrier Open/Close Time

Categories Security Turnstile Gate
Model Number: GAT-330 series
Brand Name: Goldantell
Place of Origin: Guangdong, China
MOQ: 1
Price: negotiation
Certification: CE/ROHS/FCC/IS9001
Payment Terms: L/C,T/T,Western Union
Supply Ability: 1,000pcs per month
Delivery Time: 7-9 working days after received your payment
Packaging Details: Packed in carton firstly,and then reinforced with export wooden case for outer packing
Barrier open time: 0.4 s
Communication Interface: RS-232, RS485
Operation Direction: 2-Way
Barrier motor: Brushed Motor
Protection Level: IP54
Turnstile function: Collision Avoidance
Working environment: Indoor, Outdoor
Communication protocol: RS485 TCP/IP
Passage Width: 110cm, 90cm, 60cm
Power supply: AC220V/110V
Material: Stainless Steel 304
Pass speed: 35 Persons/min
Cabinet dimension: 1200 x 280 x 1000H (mm)
Channel Width: 60cm
Access mode: single in/out or Bidirectional
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Automatic Half Height Turnstile Gate with Stainless Steel 304 IP54 Protection and 0.4s Barrier Open/Close Time

Products Description
1.The body is made from brushed stainless steel which creates a seamless and elegant design. 3 arms can rotate in one or two directions by controlled drive mechanism.
2. In case of emergency turnstile can be unlocked either manually or automatically.Robust mechanism with intelligent control unit make it more reliable.
3. It is intensive use with sooth operation. Its unique features with extensible functions allow it to integrate with various kinds of access control, including rfid / fingerprint/ qr code /barcode / ticket / ESD testing / facial recognition system.
SPECIFICATIONS FOR MACHINE
Cabinet dimension
Overall size: 1200 x 280 x 1000H (mm). The size can be custom-made.
Cabinet material
normally 304 stainless steel (SUS316 can be custom-made)
Channel Width
60cm
Access mode
single in/out or Bidirectional
Access method / system
use fingerprint, face recognition, barcode scanner or dual rfid cards
Features & Functions
-The Tripod Turnstiles are very robust products able to function inside and outside buildings.
-The Tripod Turnstile is a waist-height tripod turnstile in a self-supporting housing (2 Feet).
-The Tripod Turnstile with dropping arm to free the walkway in the event of an emergency or for certain applications
1. Security
. Active arm can drop clear (emergency or application)
. Arms cannot be removed without special tools
. Mechanism cannot be forced
2. Ergonomic
. Inactive arms do not hinder the passage
. Simple to install
3. Flexibility
. Removable end covers for easy integration of any type of access control device
. Numerous configurations covering all cases of pedestrian access control
Detailed Images
Recommend Products
There are various kinds of Turnstile/ barrier gate series optional, all can work prefer with access control system like RFID card/ Fingerprint , QR code/ barcode, facial recognication,etc.
Application
Application Place
Subway Station, Hoverport,Tourism Sports,Exhibition, Swimming Hall,Residence Area,Enterprise’s Entrance and Exit
Attendance,Gateway Guard,Charge Management,Special Access Control.

Company Introduction
Shenzhen Goldantell Technology Co.,Ltd is a leading exporter and supply chain service provider of intelligent turnstile,access control system and parking management products, starting from 2007.We also provide the customized products and OEM service. Various new collections and design are coming out each year.

Our Services & Strength

1-We have professional designer,we can do OEM and ODM.
2-CE approved, very successful experiences with European government projects.
3-Responsible sales person,with more than 4 years experiences in the turnstile trade.
4-Competitive price with high standard quality and good after-sales service.
5-We can offer products according to custom requirement of clients and offer the access control system.

Why Choose Us
Our Pre-sale & after-sale service
1, pre-sale service: good communication to better understanding of your demand,advance provide product full info.
2. on-purchase service: keep updating the production process to you,send clear
photos and testing video before shipment.
3, after-sale service: offer you the instruction, manual or detailed video to guide you quickly install and
use the product.
4. OEM/ODM service: More than 10 years powerful ODM/OEM ability, customize logo, product size, color, etc
5. professional service: 16 hours online or off-line prompt response to your inquiry.
Packing&Shipping

Packing & Shipping
* if <10pc, ship in 7 working days ; > 50, ship in 10-15 working days
* For customized product, need 2-3 longer working days.
~~~~~~~~~~~~~~~~~~~~~~~
* if <10pc, ship in 7 working days ; > 50, ship in 10-15 working days
* For customized product, need 2-3 longer working days.
