PVDF MBR Membrane with 72 m2 Surface Area and 216×2160mm Size for Immersion Negative Pressure Suction Filtration

Categories MBR Membrane
Brand Name: SINOMEMB
Model Number: SNU-HO-2-D2020AN
Certification: NSF
Place of Origin: China
MOQ: 5
Packaging Details: Standard export packaging
Core Components: MBR
Module: Out-inside
Nominal Pore Size: 0.01 μm
Size: 216×2160mm
Membrane Material: PVDF
Surface Area: 72 m2
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

PVDF MBR Membrane with 72 m2 Surface Area and 216×2160mm Size for Immersion Negative Pressure Suction Filtration

Specification
Product NameMBR Membrane Module
Membrane MaterialPVDF / PET
Membrane Shell MaterialABS
Inner and Outer Diameters of Membrane Fibers1.0/2.0 μm
PH Value Range2~12
Applicable Temperature Range8~45℃
Operating Membrane Flux15-22 L/m²·h
Operating Pressure-0.01~0.05 Mpa
Filtering Accuracy0.1μm
Filtering MethodImmersion Negative Pressure Suction Filtration
Recommended Operating CycleWater Production for 8 Minutes, Stop for 2 Minutes
MOQ1 Unit
Products Description

Partial OEM model parameters of SINOMEMB ® UF membrane

UF specifications and modelsMembrane materialOperation modeMembrane element size (mm)Effective membrane area (㎡)Nominal filter pore size (μm)
SNU-HO-2-D2020ANPVDFoutside-inΦ216*2160720.01
SNU-HO-2-D1020ANPVDFoutside-inΦ216*1120290.01

Note: The element model (membrane performance, appearance size) not mentioned can be customized according to the order quantity.
