| Categories | Electric Wire Rope Hoist |
|---|---|
| Brand Name: | JCYC |
| Model Number: | CD1/MD1 |
| Certification: | CE/ISO |
| Place of Origin: | CHINA |
| MOQ: | 1 |
| Price: | USD500 |
| Payment Terms: | D/A,L/C,D/P,T/T,Western Union |
| Supply Ability: | 300SETS/Month |
| Delivery Time: | 2-3weeks |
| Packaging Details: | Plywood cas |
| Products Name: | CD1/ MD1 Electric Wire Rope Hoist |
| Type: | Single /Double Girder |
| Color: | Red/Yellow/customized |
| Speed: | Single spped/double speed |
| MOQ: | 1SET |
| Company Info. |
| Chongqing Shanyan Crane Machinery Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
The wire rope electric hoist is a compact, lightweight, small-sized lifting equipment with versatile components and convenient operation. It primarily consists of components such as a motor, transmission mechanism, drum, and wire rope. The motor drives the transmission mechanism, causing the drum to rotate and wind up or release the wire rope, thereby achieving the lifting and moving of heavy objects. It can be used independently or in combination with bridge cranes, gantry cranes, jib cranes, and other lifting devices.
Model | CD1-0.5 | CD1-1 | CD1-2 | CD1-5 | CD1-10 |
Capacity(t) | 0.5 | 1 | 2 | 5 | 10 |
Standard lift(m) | 6-12 | 45473 | 6-30 | 45473 | 45565 |
Lifting speed(m/min) | 8 | 8 | 8 | 8 | 7 |
Running speed(m/min) | 20(30) | 20(30) | 20(30) | 20(30) | 20(30) |
Wire rope type | 6*37-4.8-180 | 6*37-7.4-180 | 6*37-11-155 | 6*37-15-200 | 6*37-17.5-20 |
I Beam track type | 16-28b | 16-28b | 20a-32c | 25a-63c | 28a-63c |
Motor power/kw | 0.8 | 1.5 | 3 | 7.5 | 13 |
Motor R.P.M(r/min) | 1380 | 1380 | 1380 | 1380 | 1380 |
Voltage(V) | 380 or customized | ||||
Frequency(Hz) | 50(60) | 50(60) | 50(60) | 50(60) | 50(60) |
Phase | 3 | 3 | 3 | 3 | 3 |
|
