| Categories | Wire Rope Mesh |
|---|---|
| Brand Name: | HUIHAOKASITE |
| Model Number: | HH-SRM-6 |
| Certification: | ISO9001-2015 |
| Place of Origin: | CHINA |
| MOQ: | 1square meters |
| Price: | USD14-USD28 Per sqaure meter |
| Payment Terms: | T/T |
| Supply Ability: | 60000m2 cable mesh within 30 days |
| Delivery Time: | 7 work days |
| Packaging Details: | rolls + carton+ pallet or according to your requests |
| Name: | Flexible Stainless Steel Cable Mesh |
| Application: | Siding Cladding |
| Rope diameter: | 1.2mm-3.2mm |
| Our services: | frame design and installtion deisgn and corner fixings |
| Mesh length: | 6000 mm |
| Maximum opening angle: | 70–75°. |
| Company Info. |
| Anping County Huihao Wire Mesh Manufacture Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
Our cable mesh and rope systems are flexible and suitable for a wide variety of applications. They can be used in both new and existing construction. we are proud to offer industry safety solutions for falling protection and more. Some of our most popular applications include: parking garage safety, Safety mesh and railings.
• Code compliant and climb-resistant.
• Install on any guardrail system.
• Exact field measurements not required.
• Simplified field installation and adjustment.
• 100% AISI 304 / 316 stainless steel.
| Item No.s | Cable Diameter | Mesh Opening Size (W×H) |
|---|---|---|
| HH-32120F | 1/8 inch (3.2 mm) | 4.75 x 8.23 inch (120 x 207.8 mm) |
| HH-32102F | 1/8 inch (3.2 mm) | 4 x 6.9 inch (102 x 176.7 mm) |
| HH-3290F | 1/8 inch (3.2 mm) | 3.55 x 6.15 inch (90 x 156 mm) |
| HH-3276F | 1/8 inch (3.2 mm) | 3 x 5.2 inch (76 x 131.6 mm) |
| HH-3251F | 1/8 inch (3.2 mm) | 2 x 3.46 inch (51 x 88.3 mm) |
| HH-24102F | 3/32 inch (2.4 mm) | 4 x 6.9 inch (102 x 176.7 mm) |
| HH-2490F | 3/32 inch (2.4 mm) | 3.55 x 6.15 inch (90 x 156 mm) |
| HH-2476F | 3/32 inch (2.4 mm) | 3 x 5.2 inch (76 x 131.6 mm) |
| HH-2460F | 3/32 inch (2.4 mm) | 2.4 x 4.16 inch (60 x 104 mm) |
| HH-2451F | 3/32 inch (2.4 mm) | 2 x 3.46 inch (51 x 88.3 mm) |
| HH-2076F | 5/64 inch (2.0 mm) | 3 x 5.2 inch (76 x 131.6 mm) |
| HH-2060F | 5/64 inch (2.0 mm) | 2.4 x 4.16 inch (60 x 104 mm) |
| HH-2051F | 5/64 inch (2.0 mm) | 2 x 3.46 inch (51 x 88.3 mm) |
| HH-2038F | 5/64 inch (2.0 mm) | 1-1/2 x 2.6 inch (38 x 65.8 mm) |
| HH-1676F | 1/16 inch (1.6 mm) | 1.2 x 2.08 inch (76 x 131.6 mm) |
| HH-1651F | 1/16 inch (1.6 mm) | 2 x 3.46 inch (51 x 88.3 mm) |
| HH-1638F | 1/16 inch (1.6 mm) | 1-1/2 x 2.6 inch (38 x 65.8 mm) |
| HH-1630F | 1/16 inch (1.6 mm) | 1.2 x 2.08 inch (30 x 52 mm) |
| HH-1625F | 1/16 inch (1.6 mm) | 1 x 1.73 inch (25.4 x 44 mm) |
| HH-1238F | 3/64 inch (1.2 mm) | 1-1/2 x 2.6 inch (38 x 65.8 mm) |
| HH-1230F | 3/64 inch (1.2 mm) | 1.2 x 2.08 inch (30 x 52 mm) |
| HH-1225F | 3/64 inch (1.2 mm) | 1 x 1.73 inch (25.4 x 44 mm) |
| HH-1220F | 3/64 inch (1.2 mm) | 4/5 x 1.39 inch (20 x 34.6 mm) |
|
