30KW VSD Direct driven oil inject screw compressor

AIRERA | 30kW VSD Direct Driven Oil-Injected Screw Compressor

Peak Efficiency, Direct Drive — The Sustainable Power Core for Large-Scale Production

The AIRERA 30kW Series is an energy-efficiency benchmark built for high-load, long-operating-hour industrial environments. By integrating 1:1 Direct Drive technology with an advanced Variable Speed Drive (VSD) system, this unit eliminates the transmission losses and unloading waste common in mid-to-large-scale compressors. Whether supporting complex automated lines or heavy manufacturing, it delivers exceptionally stable and economical compressed air, reducing energy costs by over 35% compared to traditional belt-driven models.

Advantages of AGCD VSD Oil-Inject Air Screw Compressor

With a wider frequency modulation range of 30–200 Hz, it is 15–35% more energy-efficient than most 300–100 Hz compressors on the market
Next-generation control system: We employ dual-inverter technology, retaining the original motor inverter features while also incorporating an inverter-controlled cooling fan for the main unit. This dual-inverter approach ensures the cooling system operates in a stable state, and the modular design facilitates easy maintenance.

Multi-touch color controller for simple and convenient operation and monitoring

Custom air intake system that prevents dust from entering

A three-stage filtration system removes fine particles from the air, filtering out 99.99% of impurities to ensure the quality of the air entering the unit and extend its service life

Technical Specifications - 30KW VSD Air Cooling Compressor

ITEM	UNIT	MODEL AGCD-30 VP
Free air delivery	m³/min	1.25-5 \| 1.15-4.5 \| 0.95-3.6
Max. working pressure	MPa	0.8 ~1.3
Compressor type		Oil inject screw compressor
Cooling type		Air cooling
Driven type		Direct driven
Inlet status - Temperature	℃	≤45
Inlet status - Pressure	MPa	Atmospheric pressure
Inlet status - Relative humidity		≤90%
Noise Level	dB(A)	≤72
Residual oil content	ppm	≤2
Drive rotor speed	rpm	800~3000
Compressed air outlet temperature	℃	Ambient temperature＋10
Cooling air flow	m³/hr	9200
Control mode		Intelligent controller
Safety valve set pressure	MPa	0.88 ~ 1.43
Lubricating water volume	L	30
Compressed air outlet connection		G1-1/2
Dimension - L	mm	1400
Dimension - W	mm	1000
Dimension - H	mm	1300
Net Weight	kg	740
Motor - Model		YPM160L30-30
Motor - Speed	rpm	800~3000
Motor - Rated Power	KW	30
Motor - Service factor		1.2
Motor - Protection type		IP55
Motor - Efficiency		IE3
Motor - Startup mode		Frequency conversion starting
Motor - Voltage	V	380(Special on request)
Motor - Frequency	Hz	40-150(Special on request)
Motor - Rated current	A	51
Motor - Weight of motor	kg	150

AIRERA 30kW VP Screw Air Compressor: Frequently Asked Questions (FAQ)

What is the approximate air delivery of this 30kW unit? How many pneumatic tools can it support?

A 30kW VSD compressor delivers approximately

5.0-5.5text{ m}^3/text{min}

at 0.8MPa. While the exact number of tools depends on individual air consumption, it is typically sufficient to power a medium-to-large machining workshop, a mid-scale painting line, or multiple textile production units.

Why is air-cooling recommended for high-power machines like the 30kW model?

While water-cooling is common for high power, AIRERA’s optimized air-cooling is more economical and convenient for the 30kW range. It eliminates the need for expensive cooling towers and plumbing, and removes the risks of freezing in winter or scaling in pipes. Our oversized aluminum finned radiators ensure excellent temperature control even in harsh, high-ambient conditions.

What are the benefits of VSD soft-starting for a mid-to-large motor like the 30kW?

It protects both your power grid and mechanical longevity. A 30kW motor would generate a massive current spike if started directly. VSD soft-starting allows the current to ramp up slowly from zero, preventing voltage drops that could crash other factory equipment. Simultaneously, by minimizing startup impact, the gears and bearings of the airend receive physical protection, leading to a longer service life.
