High Overload Capacity High Speed Stacking Door For Warehousing / Logistics Centers

Categories High Speed Folding Door
Brand Name: YOHO
Model Number: High Speed Stacking Door
Certification: ISO 9001/CE
Place of Origin: China
MOQ: IUNIT
Price: negotiation
Payment Terms: T/T
Supply Ability: 300 unit per month
Delivery Time: 10~15DAYS
Packaging Details: plywood package
Color: Yellow/Blue/Red/Grey/White/Transparent
PVC Door Curtain Thickness: 0.8–1.2 mm
Size: 3x3 m or customized (max size:6x8m)
Voitage: 380V or 220V
Name: High-Speed PVC Industrial Door
Panel Material: Anti-skid Checkered Plate
Material: PVC curtain / Galvanized steel / Stainless steel
Power: 0.75-1.5KW
Door Width: 1000mm–12000mm
Door Height: 1500mm–12000mm
Opening speed: 0.6–1.2 m/s (adjustable)
Closing speed: 0.6 m/s (adjustable)
Application: Warehousing And Logistics Centers
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

High Overload Capacity High Speed Stacking Door For Warehousing / Logistics Centers

High Overload Capacity High Speed Stacking Door For Warehousing And Logistics Centers

The High Speed Stacking Door for warehousing and logistics centers is designed to improve internal traffic efficiency, safety, and energy control in busy warehouse environments.

In modern logistics centers, fast and reliable door operation is critical to maintain smooth material flow between storage areas, sorting zones, and loading docks. The door features a servo-controlled motor system, durable insulated curtain, and advanced safety features, ensuring high-frequency operation and stable performance in harsh industrial conditions.

Product Parameters

ParameterDescription
Maximum DimensionsDoor width: 1000mm–12000mm, Door height: 1500mm–12000mm
Operating SpeedOpening speed: 0.6–1.2 m/s (adjustable)
Closing speed: 0.6 m/s (adjustable)
Door Curtain Material0.8–1.2 mm thick curtain; available colors: Blue, Orange, Gray
Frame MaterialStandard track frame: Galvanized steel with powder coating
Optional upgrade: Stainless steel
Sealing PerformanceHigh-quality brush sealing on tracks, bottom equipped with EPDM sealing structure
Wind ResistanceUp to Class 6 wind, can be reinforced to Class 8
Manual OperationIn case of power failure or malfunction, the door can be manually opened using a standard wrench
Power Supply RequirementsThree-phase 380V/50Hz, IP54 control box, compliant with national electrical safety standards
Insulation ProtectionIP54, waterproof and dustproof for harsh environments
Opening/Closing ControlStandard one-button operation with emergency stop; optional control methods: Radar sensor, loop detector, pull cord switch, remote control
Pre-reserved PortsElectrical system pre-reserved for: infrared safety switch, loop detector, radar sensor, pull cord switch, remote control, dual-door interlock; highly compatible

Product Advantages

Enhance Material Flow Efficiency

  • Rapid opening and closing minimize waiting times for forklifts, AGVs, and personnel
  • Supports continuous logistics operations in high-traffic areas

Improve Safety

  • Infrared safety sensors and bottom soft edge prevent collisions and accidents
  • Servo-controlled motor ensures precise stopping and safe rebound

Energy Efficiency

  • High-quality track and EPDM bottom sealing reduce air exchange
  • Maintains temperature stability in internal warehouse zones

Durability & Low Maintenance

  • Robust galvanized steel or stainless steel frame
  • Servo motor with gearbox and brake system allows thousands of cycles per day

Door Structure and Dimensions

  • Maximum Dimensions: Width 1000–12000 mm, Height 1500–12000 mm
  • Curtain Material: 0.8–2.0 mm PVC; colors: Blue, Orange, Gray
  • Frame & Track: Standard galvanized steel with powder coating; optional stainless steel
  • Wind Resistance: Class 6 (reinforced to Class 8)

Operating Speed

  • Opening Speed: 0.6–1.2 m/s (adjustable)
  • Closing Speed: 0.6 m/s (adjustable)

Applications

The High Speed Stacking Door is ideal for logistics and warehousing operations:

  • Internal corridors connecting storage, sorting, and packing zones
  • High-traffic loading and unloading areas
  • Warehouse-to-warehouse internal passages
  • Logistics centers requiring high-frequency operation and safety
  • Temperature-controlled or energy-sensitive indoor zones

FAQ

Can this door withstand high-frequency operation?

Yes. The servo motor system allows thousands of cycles per day, suitable for busy logistics centers.

Is it safe for forklift and AGV traffic?

Absolutely. Infrared sensors, soft bottom edge, and precise motor control ensure safe and reliable operation.

Can the door size and color be customized?

Yes. Width, height, and PVC curtain colors (Blue, Orange, Gray) are customizable to match warehouse layout and branding.
