Panel Solar Frame 35mm 455watt Tier 1 Factory Panel Pv Tuv Certificate Bluesun Solar Panel Cell 166mm

Categories 166mm Solar Panels
品牌: Bluesun/OEM
型号: BSM455M-HPH
原产地: Anhui, China
电池片尺寸: 166mmx166mm
类型: 打击乐, 半电池, 标准太阳能电池板
尺寸: 2094*1038 * 35mm
组件效率: 20.9%
重量: 25.5kg
产品名称: 半电池太阳能电池板144电池单390w
太阳能电池板: 单声道455瓦
保修: 25年输出功率保证
应用程序: 太阳能发电系统
接线盒: IP68额定
证书: TUV/IEC61215/IEC61730/CEC/CE/PID/ISO
前玻璃: 3.2mm高传输
TPT背板: 白色或黑色
保修期: 15年
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Panel Solar Frame 35mm 455watt Tier 1 Factory Panel Pv Tuv Certificate Bluesun Solar Panel Cell 166mm

Products Description
Perc Cell
The PERC cell has a passivated rear side and a laser grooving process, which significantly improves the cell efficiency.
Electrical Characteristics
Model Number
BSM425M-72HPH
BSM430M-72HPH
BSM435M-72HPH
BSM440M-72HPH
BSM445M-72HPH
BSM450M-72HPH
BSM455M-72HPH
Testing Condition
STC
Maximum Power (Pmax/W)
425
430
435
440
445
450
455
Open Circuit Voltage (Voc/V)
48.3
48.5
48.7
48.9
49.1
49.3
49.5
Short Circuit Current (Isc/A)
11.23
11.31
11.39
11.46
11.53
11.60
11.66
Voltage at Maximum Power (Vmp/V)
40.5
40.7
40.9
41.1
41.3
41.5
41.7
Current at Maximum Power (Imp/A)
10.50
10.57
10.64
10.71
10.78
10.85
10.92
Module Efficiency(%)
19.6
19.8
20
20.2
20.5
20.7
20.9
STC (Standard Testing Conditions): Irradiance 1000W/m², Cell Temperature 25 ℃, Spectra at AM1.5
Projects
Bluesun‘s export volume is as high as 22GW, with projects in more than 185 countries around.
Configuration:425W Solar Panel EU Stock
Installation site:Croatia
Configuration:Energy Storage with 700W Double Glass Shingled Solar Panel
Installation site:U.K.
Configuration:440W Black Frame Shingled Solar Panel
Installation site:Sweden Gothenburg
Bluesun Company
Bluesun Solar, as one of the top solar integrated solution provider in China, is a high-tech manufacturer specializing in R&D of solar panels,lithium battery and ESS.

Our Global Exhibition
INTERSOLAR EUROPE
INTERSOLAR MEXICO
INTERSOLAR AMERICA
THE FUTURE ENERGY SHOW PHILIPPINES
SOLAR SOLUTIONS INT AMSTERDAM
SOLAR & STORAGE LIVE UK
