| Categories | 2960 Switch |
|---|---|
| Brand Name: | Cisco |
| Model Number: | WS-C2960L-8TS-LL |
| Place of Origin: | Beijing, China |
| Packaging Details: | Original brand new box |
| Supply Ability: | 30 Piece/Pieces per Day |
| MOQ: | 1 pieces |
| Price: | Negotiable |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Delivery Time: | 2-3 working days |
| Product Name: | WS-C2960L-8TS-LL |
| Transmission Rate: | 10/100/1000Mbps |
| Device Type: | 8 Ports Switch |
| Switch Capacity: | 20 Gbps |
| Uplink Interfaces: | 2 x 1G SFP |
| Private Mold: | NO |
| Warranty: | One Year |
| Dimensions (W x D x H): | 4.4 x 21.5 x 26.8cm |
| IOS: | LAN Lite |
| Company Info. |
| Beijing Lianmai Tongchuang Technology Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
WS-C2960L-8TS-LL offering 8 x GigE ports, 2 x 1G SFP and LAN Lite, is one of the Cisco Catalyst 2960-L Series Switches. These 2960-L Series Switches are fixed and smart-managed Gigabit Ethernet switches that provide enterprise-class access switching for branch offices, out-of-the-wiring-closet applications, and critical Internet of Things (IoT) deployments, as well as small and medium-sized businesses. These switches are fully managed switches that offer advanced Layer 2 features as well as Power over Ethernet Plus (PoE+) power. These switches deliver enhanced network security, network reliability, and operational efficiency.
Specifications
| Product Code | WS-C2960L-8TS-LL |
| IOS | LAN Lite |
| Forwarding bandwidth | 10 Gbps |
| Switching bandwidth | 20 Gbps |
| 10/100/1000 Ethernet Ports | 8 |
| Uplink Interfaces | 2 x 1G SFP |
| Fanless | Y |
| DRAM | 512 MB |
| Flash memory | 256 MB |
| Dimensions (H x D x W) | 1.73 x 8.45 x 10.56 in. (4.4 x 21.5 x 26.8 cm) |
| Console Ports | |
| RJ45 Ethernet | 1 |
| USB mini-B | 1 |
| USB-A port for storage and Bluetooth console | 1 |
| Memory and Processor | |
| CPU | ARMv7 800 MHz |
| DRAM | 512 MB |
| Flash memory | 256 MB |
| Performance | |
| Forwarding bandwidth | 10 Gbps |
| Switching bandwidth | 20 Gbps |
| Forwarding rate (64-byte L3 packets) | 14.88 Mpps |
| Unicast MAC addresses | 8K |
| Maximum active VLANs | 64 |
| VLAN IDs available | 4094 |
| Maximum STP instances | 64 |
| Maximum SPAN sessions | 1 |
| MTU-L3 packet | 9198 bytes |
| Jumbo Ethernet frame | 10,240 bytes |
| MTBF in hours (Data) | 2,448,133 |
| MTBF in hours (PoE) | 315,044 |
| Environment | |
| Operating temperature | |
| Up to 5,000 ft | 23ºF to 113ºF (–5ºC to 45ºC) |
| Up to 10,000 ft | 23ºF to 104ºF (–5ºC to 40ºC) |
| Operating altitude | 10,000 ft (3000m) |
| Operating relative humidity | 5% to 90% at 40ºC |
| Storage temperature | –13º to 158ºF (–25º to 70ºC) |
| Storage altitude | 15,000 ft (4500m) |
| Storage relative humidity | 5% to 95% at 65ºC |
| Storage altitude | Minimum ambient temperature for cold start is 0°C (32°F) |
| Electrical | Data |
| Voltage (autoranging) | 110 to 220V AC in |
| Frequency | 50 to 60 Hz |
| Current | 0.13A to 0.22A |
| Power rating (maximum consumption) | 0.04 kVA |
Power consumption (watts) 0% traffic 10% traffic 100% traffic Weighted average |
14.8 14.9 14.2 |
| Safety and Compliance | |
| Safety | UL 60950-1 Second Edition, CAN/CSA-C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, AS/NZS 60950-1 |
| EMC: emissions | 47CFR Part 15 (CFR 47) Class A, AS/NZS CISPR22 Class A, CISPR22 Class A, EN55022 Class A, ICES003 Class A, VCCI Class A, EN61000-3-2, EN61000-3-3, KN22 Class A, CNS13438 Class A |
| EMC: immunity | EN55024, CISPR24, EN300386, KN24 |
| Environmental | Reduction of Hazardous Substances (RoHS) including Directive 2011/65/EU |
| Telco | Common Language Equipment Identifier (CLEI) code |
| U.S. government certifications | USGv6 and IPv6 Ready Logo |
| Connectors and Interfaces | |
| Ethernet interfaces | 10BASE-T ports: RJ-45 connectors, 2-pair Category 3, 4, or 5 unshielded twisted-pair (UTP) cabling |
| 100BASE-TX ports: RJ-45 connectors, 2-pair Category 5 UTP cabling | |
| 1000BASE-T ports: RJ-45 connectors, 4-pair Category 5 UTP cabling | |
| 1000BASE-T SFP-based ports: RJ-45 connectors, 4-pair Category 5 UTP cabling | |
| Indicator LEDs | Per-port status: link integrity, disabled, activity, speed, and full duplex |
| System status: system, PoE, and link speed | |
| Console cables | CAB-CONSOLE-RJ45 Console cable 6 ft. with RJ-45 |
| CAB-CONSOLE-USB Console cable 6 ft. with USB Type A and mini-B connectors | |
| Power | Use the supplied AC power cord to connect the AC power connector to an AC power outlet |
Comparison of WS-C2960L-8TS-LL and WS-C2960L-8PS-LL
| Model | WS-C2960L-8TS-LL | WS-C2960L-8PS-LL |
| IOS | LAN Lite | LAN Lite |
| Forwarding bandwidth | 10 Gbps | 10 Gbps |
| Switching bandwidth | 20 Gbps | 20 Gbps |
| 10/100/1000 Ethernet Ports | 8 | 8 PoE+ |
| Available PoE Power | N/A | 67W |
| Uplink Interfaces | 2 x 1G SFP | 2 x 1G SFP |
|
