Smooth and Precise Leveling with ShangChai Engine Concrete Screed Vibrator

Smooth and Precise Leveling with ShangChai Engine Concrete Screed Vibrator

Smooth and Precise Leveling with ShangChai Engine Concrete Screed Vibrator
Smooth and Precise Leveling with ShangChai Engine Concrete Screed Vibrator
Categories Road Construction Machinery
Applicable Industries: Machinery Repair Shops, Manufacturing Plant, Farms, Home Use, Retail, Construction works , Energy & Mining, Other
Showroom Location: None
Video outgoing-inspection: Provided
Machinery Test Report: Provided
Marketing Type: Hot Product 2024
Warranty of core components: 1 Year
Core Components: Engine, Bearing, Motor
Condition: New
Production Capacity: 5-10 m / min
Power: 1.2 kw
Max. Paving Thickness: 50 mm
Place of Origin: Henan, China
Brand Name: Be-Focus
Dimension(L*W*H): 600*450*450 mm
Weight: 28 kg
Warranty: 1 Year
Hydraulic Pump Brand: Customized
Hydraulic Valve Brand: Huade
Engine Brand: ShangChai
UNIQUE SELLING POINT: Easy Maintenance
Product name: Road Paver Leveling Machine
Key words: Concrete Paver Leveling Machine
Application: Concrete Surface Level
Engine: Gasoline/Electric/Diesel Engine
Ruler Length: 2-10 m customized
Fuel Tank: 3.6L
Control type: Hand-held
Max.Speed: 3600rpm
Max.output: 5.5hp
Certification: CE/ISO9001
Price: $168.00/sets 1-4 sets
MOQ: 1 set
Contact Now
Company Info.
Henan Beifuke Machinery Equipment Co., Ltd.
Verified Supplier
View Contact Details
Product List
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Smooth and Precise Leveling with ShangChai Engine Concrete Screed Vibrator

Product Description
The vibrating screed rule is mainly used for concrete construction, which can scrape the concrete, discharge the bubbles in the concrete and enhance the density of the concrete. It is suitable for large-area floor construction such as various standard factory buildings, parking lots, warehouses and frame buildings.
Gasoline Low Price Vibration Ruler Concrete Compactor Concrete Levelers Handheld Concrete Vibratory Screed Ruler
Product Paramenters
Metric
Model
BS-1
BS-2
BS-3
BS-4
BS-5
Dimensions
420*290*1000mm
420*290*960mm
420*300*980mm
420*300*980mm
2000*300*1200mm
Type
gasoline
gasoline
gasoline
gasoline
gasoline
Screed size
2-5m customized
2-5m customized
2-5m customized
2-5m customized
8m
customized
Max output
1.6 kw
0.33kw
1.2 kw
1.2 kw
3 kw
Max speed
10000rpm
10000rpm
10000rpm
10000rpm
10000rpm
Drive System
fully enclosed shaft
Aluminum alloy closed shaft
Aluminum alloy closed shaft
Flexible shaft
Flexible shaft
Weight
28 kg
25kg
24 kg
26 kg
40kg
Product details

Product Advantages

1. It replaces the two processes of roller and scraping ruler in the traditional construction process, reduces the cost and improves the efficiency. 2. The aluminum alloy material used in the fuselage is light, easy to use, safe and high in flatness. 3. It uses titanium magnesium aluminum alloy scraper with high flatness. 4. Its handle height can be adjusted, suitable for operators of different heights. 5. Its shock absorber can reduce the vibration of the upper engine and armrest. 6. Its blade is easy to replace, easy to operate and easy to maintain.
Pruduct Show
Usage scenario
Product packaging
The machine body and corresponding accessories are packed with plastic film, and then the machine and accessories are shipped in fumigant-free wooden boxes.
Company Profile
Henan Be Focus Mechanical Equipment Co., Ltd., which was founded in 1998, is a high-tech enterprise specializing in the design, R&D and innovation of concrete machinery for the engineering construction of mines, tunnel bridges, subway culverts,hydro power projects, underground projects and coal mine tunnels, as well as production and sales services.
Corporate Culture
All employees of thecompany adhere to the principle that credibility is life, quality is survival, quality is used to gain trust,brand is used toextract value, create differences, and service is used to win competition. They are your trusted and long-term partners.
Excellent partner
Our company has long-term cooperation with many large enterprises at home and abroad, including the world's leading enterprises and national enterprises in the industry, which represents the recognition of our strength by our partners.
Industry Certificate
FAQ
1.Q: Are you the original manufacturer? A: Yes. We are a foreign trade company integrating industry and trade, with our own independent production factory. 2.What are your warranty terms? A: We provide different warranty periods for different products. For detailed warranty terms, please contact us. 3. Q: Delivery time A: It takes 3-5 days for inventory products, and customized products need to be determined according to products 4. Q: What's the payment you accept ? A: As usual our payment is 30%T/T as deposit, and the 70% balance against the copy of B/L.Also we accept the payment such as L/C ,Escrow, Western Union Or VISA .
