| Categories | Core Industrial PC |
|---|---|
| Brand Name: | SMATIPC |
| Model Number: | IEXP-732 |
| Certification: | CE, FCC, CCC |
| Place of Origin: | China |
| MOQ: | 1 |
| Price: | Negotiable |
| Payment Terms: | T/T,Paypal |
| Supply Ability: | 9000 Pcs/Month |
| Delivery Time: | 5-7 Days |
| Product Collection: | 12th Generation Intel Core i3 Processors |
| CPU: | I3-12300T |
| Total Cores: | 4 |
| Total Threads: | 8 |
| Chipset: | H610 |
| Processor Base Power: | 35 W |
| Humidity: | 5%~95% |
| Power Supply: | DC 12V-19V Input |
| Company Info. |
| Shenzhen Xin Saike Technology Co.,Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Intelligent Embedded Computer With Intel 12th Gen Intel Core I3
. The IEXP-732 is suitable for use in a variety of harsh environments. It can withstand temperature extremes of -20°C to 60°C and humidity levels ranging from 5% to 95%. Its weight of 3.27kg makes it easy to install and transport. And it support for up to 64GB of DDR4 memory. This allows you to tailor the system to your specific needs and ensure that it can handle even the most demanding applications. The Realtek RTL8111H LAN type provides reliable and fast network connectivity
| Parameter | Storage | |||
| Processor | Intel Core i3-12300T (4 core 8 threads, Max 4.2GHz) Intel Core i5-12500T (6 core 12 threads, Max 4.4 GHz) Intel Core i7-12700T (12 cores 20 threads, Max 4.7GHz) | M.2 | 1xM.2 2280 M-key slot ( support PCIE3.0 x4 NVME) (support SATA SSD requires resistor switching signal) | |
| Chipset | H610 | SATA | 1x2.5 inch HDD | |
| Memory | 2xDDR4 3200MHz SODIMM slot, Max 64 GB | Expansion | ||
| Graphics Card | Mini PCIE | 1xfull-length Mini PCIE slot (support PCIE & USB2.0 singal, Optional 4G/WIFI/BT), internal Nano-SIM card slot | ||
| Graphics | Integrated Intel® UHD Graphics 730/770 (synchronous/asynchronous dual display) | |||
| Display | 1xHDMI Port (Resolution 3840x2160 @60Hz) 1xVGA (Resolution 1920x1080 @60Hz) | Dimension | ||
| Size | 215 x 203 x 75 mm 8.46 x 8.0 x 3.0 inch | |||
| Ethernet Network | Weight | 3.27 kg (Barebone) 7.2lb | ||
| Lan Port | 2xRealtek RTL8111H Gigabit LAN | Installation | Wall-mounted (standard included), desktop (default support) | |
| I/O | Environment | |||
| USB | 2xUSB3.0, 6xUSB2.0 | Temperature | -20℃~ +60℃, Surface air flow | |
| COM | 4xCOM (COM1/2 RS232/485 Optional) | Humidity | 5%~95% Non-condensing state | |
| Audio | 1xLine out, 1xMIC | Other Function | Power-on, Timing boot, Wake on LAN, PXE boot, watchdog (level 0-255), TPM2.0 security encryption | |
| Power Supply | ||||
| Power Supply | 1xDC Input (5.5x2.5mm), support 12V~19V | Application | Industrial automation, medical, logistics, transportation, warehousing, e-education and other fields | |
Some of the application scenarios for the IEXP-732 include:
|
