| Categories | VSD Oil injected Screw Compressor |
|---|---|
| Brand Name: | AIRERA |
| Model Number: | AGCD-110D C VP |
| Certification: | ISO、CE、TUV |
| Place of Origin: | made in China |
| MOQ: | 1 unit |
| Price: | Negotiable |
| Payment Terms: | TT/LC,Western Union,D/P,D/A |
| Supply Ability: | 2,000-3,000 per month |
| Delivery Time: | 5-15 days |
| Packaging Details: | wooden case |
| Cooling air flow（m3/hr）: | 13200 |
| Application: | Medical, Pharmaceutical, Food Processing |
| Oil Content: | Oil inject |
| Working Pressure: | 0.8-1.3Bar |
| Cooling type: | Air cooling |
| Driven type: | Direct driven |
| Company Info. |
| Shanghai Bestcomp Compressor Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
The AIRERA 110kW series is engineered specifically for large-scale enterprises seeking maximum productivity and ultimate cost control. By seamlessly integrating 1:1 zero-loss direct drive technology with advanced Variable Speed Drive (VSD), we provide a rock-solid power foundation for your heavy industrial lines while pushing energy efficiency to new heights.
With a wider frequency modulation range of 30–200 Hz, it is 15–35% more energy-efficient than most 300–100 Hz compressors on the market
Next-generation control system: We employ dual-inverter technology, retaining the original motor inverter features while also incorporating an inverter-controlled cooling fan for the main unit. This dual-inverter approach ensures the cooling system operates in a stable state, and the modular design facilitates easy maintenance.
PCB coating enhances environmental resistance; an excellent heat dissipation design allows operation at ambient temperatures up to 50°C. The system automatically adjusts the output rating based on temperature rise conditions to maintain the inverter’s sustained high-efficiency operation.
Specialized Oversized Inlet Valve
· Normally closed, oversized bore, ultra-low pressure drop;
· Low failure rate, long service life;
·The more efficient SF 1.2 IP55 VSD motor complies with IE5 and MEPS standards and meets the national Class 1 energy efficiency standards
| ITEM | UNIT | MODEL AGCD-110 VP |
|---|---|---|
| Free air delivery | m³/min | 5.2-20.5 | 4.5-17.50| 3.70-14.5 |
| Max. working pressure | MPa | 0.8 ~1.3 |
| Compressor type | Oil inject screw compressor | |
| Cooling type | Air cooling | |
| Driven type | Direct driven | |
| Inlet status - Temperature | ℃ | ≤45 |
| Inlet status - Pressure | MPa | Atmospheric pressure |
| Inlet status - Relative humidity | ≤90% | |
| Noise Level | dB(A) | ≤79 |
| Residual oil content | ppm | ≤2 |
| Drive rotor speed | rpm | 800~3000 |
| Compressed air outlet temperature | ℃ | Ambient temperature＋10 |
| Cooling air flow | m³/hr | 13200 |
| Control mode | Intelligent controller | |
| Safety valve set pressure | MPa | 0.88 ~ 1.43 |
| Lubricating water volume | L | 70 |
| Compressed air outlet connection | G2-1/2 | |
| Dimension - L | mm | 2540 |
| Dimension - W | mm | 1640 |
| Dimension - H | mm | 1800 |
| Net Weight | kg | 1850 |
| Motor - Model | YPM280S30-110 | |
| Motor - Speed | rpm | 800~3000 |
| Motor - Rated Power | KW | 110 |
| Motor - Service factor | 1.2 | |
| Motor - Protection type | IP55 | |
| Motor - Efficiency | IE3 | |
| Motor - Startup mode | Frequency conversion starting | |
| Motor - Voltage | V | 380(Special on request) |
| Motor - Frequency | Hz | 50-200(Special on request) |
| Motor - Rated current | A | 188 |
| Motor - Weight of motor | kg | 922 |
This is central to AIRERA’s engineering. We use a triple-independent thermal control system:
High-capacity oil cooling circuit: Precisely regulates oil temperature entering the air end.
Heavy-duty oversized air-cooled radiator: Features 25% more heat exchange surface than standard models with intelligent centrifugal fans.
Low-temperature oil return technology: Ensures discharge temperatures stay well below the oil carbonization point, even in scorching summers, guaranteeing 24/7/365 stability.
Excellent. We equip this model with a reinforced 5-stage oil-gas treatment system, utilizing centrifugal, gravity, and multi-layer nano-scale separation filters. Residual oil is kept at ≤3ppm. When paired with AIRERA downstream equipment (dryers and precision filters), it easily meets the stringent requirements of laser cutting, automotive painting, and high-end manufacturing.
|
