| Categories | VSD Oil injected Screw Compressor |
|---|---|
| Brand Name: | AIRERA |
| Model Number: | AGCD-90D C VP |
| Certification: | ISO、CE、TUV |
| Place of Origin: | made in China |
| MOQ: | 1 unit |
| Price: | Negotiable |
| Payment Terms: | TT/LC,Western Union,D/P,D/A |
| Supply Ability: | 2,000-3,000 per month |
| Delivery Time: | 5-15 days |
| Packaging Details: | wooden case |
| Cooling air flow（m3/hr）: | 12200 |
| Application: | Medical, Pharmaceutical, Food Processing |
| Oil Content: | Oil inject |
| Working Pressure: | 0.8-1.3Bar |
| Cooling type: | Air cooling |
| Driven type: | Direct driven |
| Company Info. |
| Shanghai Bestcomp Compressor Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
In the pursuit of balancing massive productivity with low-carbon operations, the AIRERA 90kW series stands as the definitive choice. As the central engine of your factory, this model integrates 1:1 Direct Drive technology with advanced VSD algorithms, providing heavy-duty users with a continuous, cost-effective air solution.
Multi-touch color controller for simple and convenient operation and monitoring
Upgraded high-efficiency screw compressor heads for greater airflow
By selecting low-speed screw rotors and the most suitable motors, and pairing them with main units optimized for specific speeds, we ensure that each rotor operates at its optimal speed, achieving the best possible energy efficiency ratio.
·The more efficient SF 1.2 IP55 VSD motor complies with IE5 and MEPS standards and meets the national Class 1 energy efficiency standards
| ITEM | UNIT | MODEL AGCD-90 VP |
|---|---|---|
| Free air delivery | m³/min | 4.0-15.3 | 3.8-14.30| 3.0-12.0 |
| Max. working pressure | MPa | 0.8 ~1.3 |
| Compressor type | Oil inject screw compressor | |
| Cooling type | Air cooling | |
| Driven type | Direct driven | |
| Inlet status - Temperature | ℃ | ≤45 |
| Inlet status - Pressure | MPa | Atmospheric pressure |
| Inlet status - Relative humidity | ≤90% | |
| Noise Level | dB(A) | ≤79 |
| Residual oil content | ppm | ≤2 |
| Drive rotor speed | rpm | 800~3000 |
| Compressed air outlet temperature | ℃ | Ambient temperature＋10 |
| Cooling air flow | m³/hr | 12200 |
| Control mode | Intelligent controller | |
| Safety valve set pressure | MPa | 0.88 ~ 1.43 |
| Lubricating water volume | L | 70 |
| Compressed air outlet connection | G2 | |
| Dimension - L | mm | 2100 |
| Dimension - W | mm | 1300 |
| Dimension - H | mm | 1500 |
| Net Weight | kg | 1650 |
| Motor - Model | YPM225M30-90 | |
| Motor - Speed | rpm | 800~3000 |
| Motor - Rated Power | KW | 90 |
| Motor - Service factor | 1.2 | |
| Motor - Protection type | IP55 | |
| Motor - Efficiency | IE3 | |
| Motor - Startup mode | Frequency conversion starting | |
| Motor - Voltage | V | 380(Special on request) |
| Motor - Frequency | Hz | 50-200(Special on request) |
| Motor - Rated current | A | 152.3 |
| Motor - Weight of motor | kg | 566 |
This is exactly what the AIRERA 90kW series is built for. It is engineered for 100% continuous duty cycle. The direct-drive structure minimizes mechanical failure points, while the VSD system reduces motor heat. Paired with our reinforced forced-cooling system, this unit is capable of handling 24/7/365 high-intensity operation in demanding environments.
|
